MINING METHOD OF THE WEEK - SUBLEVEL LONGHOLE!!

This bulk underground mining method involves mining large amounts of material from a single stope – similar to cut and fill, this method starts at the bottom of a level and moves upward. Ore is removed from the bottom, and then more ore is blasted from a higher level that falls to the same level to be removed, with the process repeating up the ore body. The supporting walls need to be very strong in order to support the large underground openings that will be created by this process - New Pacific Metals Corp.

MINING ROCKSTAR OF THE WEEK - ANDALUSITE!!

Andalusite is a rock-forming mineral that is mined for use in high-temperature refractories. Gem-quality specimens are cut into faceted gems and cabochons. Andalusite forms during the regional metamorphismof shale. It is found in schist and gneiss at some present and ancient convergent plate boundaries where the rocks have been exposed to the temperatures and pressures needed for its formation. In these rocks, andalusite is often associated with kyanite and sillimanite. Andalusite also forms during the contact metamorphism of argillaceous rocks. In this situation, it can form within the metamorphosed rock or in veins and cavities within the igneous rock. It can be associated with cordierite

OCT MINE DESIGN & MINE SCHEDULING COURSES

For those who don't have the software but would like exposure to mine design and scheduling, and fully understand the life of mine cycle. The courses are presented at the university of Pretoria, 1 to 5 October. CPD points also awarded for professionally registered persons. Kindly visit our website for course detail: https://www.schoolofrockmining.com/upcoming-course-details

SHOWCASE MINE OF THE WEEK - SAVUKA GOLD MINE!!

Savuka gold mine, also located in the West Wits region of South Africa and operated by AngloGold Ashanti, is the third deepest mine in the world. The mine exploits the gold contained reefs at a depth of more than 3.7km. The mining method at Savuka was recently converted from longwall to sequential grid mining. Savuka shares a common processing plant with the TauTona mine. The shafts and infrastructure at Savuka were damaged by a seismic event in 2008. The mining operations were, however, completely restored in 2011. Savuka produced 37,000 oz of gold in 2012. The mine was left with 0.56 million oz of gold reserves by the end of that year. AngloGold Ashanti is considering incorporating Savuka

WORLD'S LARGEST EXCAVATORS - KOMATSU PC5500!!

The Komatsu PC5500-6 is the ninth biggest hydraulic mining excavator in service, with an operating weight of up to 495t with the shovel attachment. The excavator weighs up to 500t, has 8.6m high cab and an undercarriage that is 9.72m long and 7.54m wide. The excavator’s shovel and backhoe bucket capacity is 29m³. The crowd force and the breakout forces of the shovel are 1,870kN and 1,865kN respectively. The shovel’s maximum digging reach is 16.5m and the breakout and tear out forces during backhoe operation are 1,450kN and 1,290kN respectively. The maximum digging reach of the backhoe bucket is 19.8m. The Komatsu PC5500-6 is powered by two 12-cylinder Komatsu SDA12V159E-2 diesel engines prod

SEPT ONLINE MINE PLANNING SOFTWARE CLASSES

Are you newly appointed and need to learn mine planning software? Or perhaps a bit rusty after all these years? Don't despair, one or two of the sessions below will get you on the right track! info@schoolofrockmining.com

WORLD'S LARGEST DUMP TRUCKS - HITACHI EH5000AC!!

The Hitachi EH5000AC-3 has a payload capacity of 326t, making it the 10th biggest dump truck in the world. It is Hitachi’s latest and largest rigid frame dump truck and was introduced at MINExpo International 2012 in Las Vegas, Nevada, in 2012. The gross machine operating weight of Hitachi EH5000AC-3 is 551t. The overall length of the truck is 15.51m. The width and loading height are 8.6m and 7.41m respectively. The truck uses the low emission Cummins QSKTTA60-CE diesel engine with 16 cylinders. The rated power output of the four-cycle engine is 2,850HP. The vehicle uses Hitachi’s IGBT AC electric drive system and runs at speeds of up to 56km/h - Mining Technology.

MINING METHOD OF THE WEEK - SHRINKAGE STOPING!!

The shrinkage stoping method is similar to cut and fill, but instead of removing the ore after blasting and backfilling, the initial broken ore is left in the void to create a working platform for the next level (and to support the wall stability of the stope). After all the planned levels have been blasted, then all of the ore is removed for processing. This method is very selective and keeps dilution low, but requires many active stopes because ore is not removed from each mining area until completion – meaning longer lead times for ore to get to the process plant compared to cut and fill operations - New Pacific Metals Corp.

METAL ROCKSTAR OF THE WEEK - TITANIUM!!

Titanium is a silver metal that is strong, resistant to corrosion, and inert. It is the ninth most abundant element in Earth's crust. Instead of occurring in large deposits, small amounts of titanium occur in almost every rock. Titanium is an important constituent in a small number of minerals. About 90% of the titanium in Earth's crust occurs in Ilmenite, a mineral that most people have never heard of. It is an iron titanium oxide with a chemical composition of FeTiO3. The rest of Earth's near-surface titanium is in minerals such as anatase, brookite, leucoxene, perovskite, rutile, and sphene. Many people know that it is used in jewelry, prosthetics, tennis rackets, goalie masks, scissors,

SHOWCASE MINE OF THE WEEK - DRIEFONTEIN MINE!!

The Driefontein mine, owned by Sibanye Stillwater, is located near Carletonville in the Gauteng Province of South Africa. The mine lies within the West Wits Line Goldfield of the Witwatersrand Basin. It is currently the fourth deepest mine in the world with its depth extended up to 3.4km. The Driefontein mine operation could be traced back to 1952. The mine consists of eight producing shaft systems extracting ore from three reefs, namely Ventersdorp Contact Reef (VCR), Carbon Leader Reef (CLR) and the Middelvlei Reef. Driefontein uses a combination of longwall and scattered mining methods. The mine produced 709,800oz of gold during 2010. The mine site includes three metallurgical plants, alo

WORLD'S LARGEST EXCAVATORS - HITACHI EX5500-6!!

In position number eight is the Hitachi EX5500-6, which was launched in 2008. The standard model has an operating weight of 522t and comes in an electric version with an operating weight of 516t. The overall cab height is 8.6m and the undercarriage length and width are 9.35m and 7.4m respectively. The loading shovel bucket capacity of the excavator is 27m³ and the backhoe bucket capacity is 29m³. The crowd force and the breakout force of the loading shovel are up to 1,570kN. The crowd force and the digging force of the backhoe are 1,240kN and 1,370kN respectively. Two 16-cylinder Cummins QSKTA50-CE diesel engines producing 2,800hp at 1,800rpm power the excavator. The Hitachi EX5500E-6 comes

WORLD'S LARGEST DUMP TRUCKS - CATERPILLAR 795F AC!!

The Caterpillar 795F AC has a payload capacity of 345t, and is the world's 9th largest dump truck. The haul-truck features modular design and offers two body options including the popular MSD (mine specific design) and the gateless coal body. The gross machine operating weight of Caterpillar 795F AC is 628t. The truck’s overall length is 15.14m. The overall width and the loading height are 8.97m and 7.04m respectively. The vehicle is powered by Cat C175-16 diesel engine with a gross generating capacity of 3,400HP. The truck uses AC electric drive system solely designed and developed by Caterpillar, and runs at a top speed of 64km/h - Mining Technology.

MINE PLANNING BASICS FRIDAY - BOARD & PILLAR COAL MINING!!

This one is for you James! The board & pillar mining method consists of driving a series of narrow roads, separated by blocks of solid coal, parallel to one another, and connecting them by another set of narrow parallel road ways driven nearly at right angles to the first set. The coal pillars formed are extracted after the development of the mine leasehold and this later stage of extracting coal from pillars is known as depillaring - Mining Funda.

ROCKSTAR OF THE WEEK - GOLD!!

Gold is called a "noble" metal (an alchemistic term) because it does not oxidize under ordinary conditions. Its chemical symbol Au is derived from the Latin word "aurum." In pure form gold has a metallic luster and is sun yellow, but mixtures of other metals, such as silver, copper, nickel, platinum, palladium, tellurium, and iron, with gold create various color hues ranging from silver-white to green and orange-red. Pure gold is relatively soft - it has about the hardness of a penny. It is the most malleable and ductile of metals. The specific gravity or density of pure gold is 19.3 compared to 14.0 for mercury and 11.4 for lead - geology.com

SHOWCASE MINE OF THE WEEK - KUSASALETHU GOLD MINE!!

The Kusasalethu gold mine operated by Harmony is located 75km west of Johannesburg, on the West Wits Line near Carletonville, Gauteng, in South Africa. It is currently the fifth deepest mine in the world as it exploits the Ventersdorp Contact Reef (VCR) up to a depth of 3,276m below the surface. Kusasalethu was formerly known as Elandskraal gold mine. Elandskraal, which started operation in 1978, was comprised of two mines namely Elandsrand and Deelkraal. The Kusasalethu operation comprises of twin vertical and twin sub-vertical shaft systems. The mine employs conventional mining methods in a sequential grid layout. The extracted ore is processed at the nearby Kusasalethu plant. The Kusasale

WORLD'S LARGEST EXCAVATORS - LIEBHERR R 996 B!!

The Liebherr R 996 B is ranked at number six in the world. The excavator’s operating weight with shovel attachment is 676t and 672t with the backhoe attachment. The vehicle has a cab height of 9.26m and an undercarriage of 10m in length and 7.9m in width. The shovel and backhoe capacity of the Liebherr R 996 B excavator is 36m³. The digging and the breakout forces during backhoe operation are 1,500kN and 1,670kN respectively. The maximum crowding force and the breakout force of its shovel are 2,430kN and 1,905kN respectively. The Liebherr R 996 B is powered by two 16-cylinder Cummins K 1800 E diesel engines producing 3,000hp at 1,800rpm - Mining Technology.

WORLD'S LARGEST DUMP TRUCKS - BELAZ 75600!!

The Belaz 75600 is currently the eighth largest mining dump truck in the world. It is the first generation model of Belaz’s 7560 class mining trucks designed for transporting rock-mass at deep open-pit mines under different climate conditions. The haul truck offers a payload capacity of 352t. The maximum gross weight of Belaz 75600 is 617t. The overall length, width and loading height are 14.9m, 9.6m and 7.47m respectively. The vehicle is powered by a four-cycle turbocharged diesel engine with 18 v-type cylinders. The gross power output of the engine is 3,500HP. The traction alternator for the vehicle is provided by Kato and the traction motors are provided by Siemens. Maximum travel speed o

SHOWCASE MINE OF THE WEEK - MOAB KHOTSONG GOLD MINE!!

Moab Khotsong gold mine is one of AngloGold Ashanti’s Vaal River operations in South Africa. The mine is located around 180km south-west of Johannesburg near the towns of Orkney and Klerksdorp. The mine is in production since 2003. It currently ranks as the sixth deepest mine in the world, with its mining depth ranging between 2.6km and 3.054km below surface. The mine exploits the Vaal Reef (VR) through three mining layers, namely the Top, Middle and Lower Mines. Moab Khotsong employs a scattered mining method with an integrated backfill support system. The mine produced 162,000 ounces of gold grading 0.238oz/t in 2012. The ore reserve stood at 6.61Moz grading 10.02g/t as of December 2012. A

WORLD'S LARGEST EXCAVATORS - HITACHI EX5600-6!!

With an operating weight of up to 537t, the Hitachi EX5600-6 is the seventh biggest hydraulic mining excavator in the world. It was launched in 2012 and succeeded the EX5500-6 model. The operating weight of the EX5600-6 with shovel attachment is 533t. The overall cab height of the excavator is 8.6m and the undercarriage length and width are 9.35m and 7.4m respectively. The loading shovel bucket capacity of the excavator is up to 29m³ and the backhoe bucket capacity is up to 34m³. The crowding and breakout forces of the shovel are 1,520kN and 1,590kN respectively. The crowd force and digging force during backhoe operation are 1,300kN and 1,480kN respectively. The Hitachi EX5600-6 comes with t

WORLD'S LARGEST DUMP TRUCKS - TEREX MT 5500AC!!

The Terex MT 5500AC, also known as the Unit Rig MT 5500AC, ranks as nr 7 of the biggest mining dump trucks in the world. The 360t payload capacity vehicle is used for high volume surface mining. The maximum gross vehicle weight of Terex MT 5500AC is 598t. The overall length is 14.87m, while the width and loading height are 9.05m and 7.67m respectively. The vehicle is powered by a four-stroke Diesel engine rated at 3,000HP with 16 cylinders. The vehicle uses AC electric drive system and travels at a maximum speed of 64km/h - Mining Technology.
